Hybrid Scanning, Metrology-Grade Accuracy
Artec Neo is a handheld, wireless, hybrid 3D scanner engineered for metrology-grade accuracy of 0.025 mm. It combines target-based and target-free scanning in one device, so you can apply targets only where tolerances must hold — and skip them everywhere else.
Built for reverse engineering and inspection, Neo captures full-color texture, reaches deep holes, channels, and recesses, and recovers tracking quickly after a loss.
One Scanner, Two Ways to Track
Switch between modes within a single scan and a single dataset.
Up to 0.025 mm Accuracy
0.025 mm accuracy with targets and 0.050 mm without, verified per VDI/VDE 2634 Part 3.
8 Million Points/s
Fast capture with no target placement needed for target-free work, at up to 15 fps real-time fusion.
Wireless Freedom
A built-in battery and Wi-Fi let you scan untethered, with a wired Thunderbolt connection also available.
Available Models
Artec Neo is offered as a single model.
Artec Neo
Best for: inspection and reverse engineering that mixes high-tolerance and free-form areas.
- Artec Neo hybrid 3D scanner
- 4 batteries — 40–50 minutes of continuous scanning per set
- A set of Artec-branded retroreflective targets
- Per-unit accuracy certificate
- AC/DC power adapter (DC 24 V)
- 2-year warranty
Verified Accuracy You Can Document
Neo's accuracy is verified per VDI/VDE 2634 Part 3 and backed by an ISO/IEC 17025-accredited lab, with a per-unit accuracy certificate for your quality records.
- Full-color 5 MP texture to document surface condition
- Access to tight areas, deep holes, channels, and recesses
- Combine data with other Artec scanners such as Leo and Ray II
Hybrid Tracking Modes
Target-Based
0.025 mm accuracy and 0.025 mm + 0.035 mm/m volumetric accuracy, using retroreflective targets where tolerances are tight.
Target-Free
0.050 mm accuracy and 0.050 mm + 0.3 mm/m volumetric accuracy, using geometry and texture tracking with no targets to place.
Use both in a single scan: targets where it counts, target-free everywhere else.
Artec Studio & Inspection Software
Export to Your Inspection Workflow
Neo works with Artec Studio and exports to Geomagic, PolyWorks, and SolidWorks, so scan data flows straight into inspection and CAD workflows.
Full Specifications
Resolution & Accuracy
| Accuracy (With Targets) | 0.025 mm |
| Volumetric Accuracy (With Targets) | 0.025 mm + 0.035 mm/m |
| Accuracy (Without Targets) | 0.050 mm |
| Volumetric Accuracy (Without Targets) | 0.050 mm + 0.3 mm/m |
| Mesh Resolution | 0.050 mm |
| Acceptance Test | VDI/VDE 2634 Part 3, in an ISO/IEC 17025-accredited lab |
Scanning Range & Speed
| Object / Area Size | S–M |
| Working Distance | 0.19–0.3 m |
| Volume Capture Zone | 1,800 cm³ |
| Linear FOV (H × W), Closest Range | 128 × 104 mm |
| Linear FOV (H × W), Furthest Range | 171 × 152 mm |
| Depth of Field | 110 mm |
| 3D Reconstruction Rate (Real-Time Fusion) | Up to 15 fps |
| Data Acquisition Speed | Up to 8 million points/s |
| Scanning Algorithms | Target compatibility, target-free geometry and texture tracking, hybrid mode |
Hardware & Texture
| Scanner Type | Handheld, wireless |
| Texture Resolution | 5 MP |
| Color Depth | 24 bpp |
| 3D Light Source | 450 nm blue LED structured light |
| Texture Illumination | White LED, CRI > 95, 4000 K |
| Power Source | AC/DC power adapter, DC 24 V |
| Interface | Thunderbolt 4 compatible, Wi-Fi |
| Dimensions (H × D × W) | 187 × 156 × 118 mm |
| Weight | 1.3 kg (with batteries) |
| Warranty | 2 years |
Software & System Requirements
| Software | Artec Studio |
| Exports To | Geomagic, PolyWorks, SolidWorks |
| Supported OS | Windows 11 |
| Recommended Computer | 13th or 14th Gen Intel Core i7 or i9, RTX 4070 8 GB |
| Minimum Computer | 12th Gen Intel Core i9, RTX 4060 8 GB |
| Mesh Export Formats | OBJ, PLY, WRL, STL, AOP, ASC, PTX, E57, XYZRGB |
| CAD Export Formats | STEP, IGES, X_T |
| Measurement Export Formats | CSV, DXF, XML |
